Parts Information
Field Replaceable Parts List
Appendix A
144
Rack Server
28 Server - Assembly - Rack latch right A7231-04023 A7231-04023 n/a
29 Server - Assembly, Rack bezel right A7231-04053 A7231-04053 n/a
30 Server - Assembly - Rack left bezel with rack latch A7231-04055 A7231-04055 n/a
Server Rack Nameplate (rx2620) A7136-40002 A7136-40002 n/a
Plastic and Metal Parts
Filler, Slimline carbon A7231-40027 A7231-40027 n/a
HDD Filler - Carbon A6198-60003 A6198-60003 n/a
Assembly - Fan Cage A7231-04004 A7231-04004 n/a
16 Assembly - PCI Cage A7231-04006 A7231-04006 n/a
3 Assembly - Plastic turbocooler duct A7231-04034 A7231-04034 n/a
Assembly - Plastic turbocooler duct (Montecito CPU) AD117-3400A AD117-3400A n/a
ECI Cover Plate A7231-00072 A7231-00072 n/a
1 Assembly - Top Cover A7231-04003 A7231-04003 n/a
Assembly- Memory air flow guide A7231-04049 A7231-04049 n/a
Cables
IDE Cable A7231-63002 A7231-63002 n/a
IDE Cable - (RoHS) A7231-63026 A7231-63026 n/a
Status Panel Cable A7231-63003 A7231-63003 n/a
Status Panel Cable - (RoHS) A7231-63027 A7231-63027 n/a
Disk Power A7231-63004 A7231-63004 n/a
Disk Power - (RoHS) A7231-63028 A7231-63028 n/a
SCSI - Channel A A7231-63017 A7231-63017 n/a
SCSI - Channel A - (RoHS) A7231-63038 A7231-63038 n/a
SCSI - Channel B A7231-63018 A7231-63018 n/a
SCSI - Channel B - (RoHS) A7231-63039 A7231-63039 n/a
Single channel SCSI A7231-63024 A7231-63024 n/a
Dual channel SCSI A7231-63025 A7231-63025 n/a
Super 80 mm Fan A7231-63005 A7231-63005 n/a
Super 80 mm Fan - (RoHS) A7231-63030 A7231-63030 n/a
80 mm Fan A7231-63006 A7231-63006 n/a
80 mm Fan - (RoHS) A7231-63029 A7231-63029 n/a
Table A-1 Parts List (Continued)
Item
No.
Description
Mfg. Part
Number
Part Number
Replacement
Part
Number
Exchange
