4. Remove the four guide screws from the hard drive and retain them for later use.
Installing a SAS hard drive
1. Disconnect power from the system (Predisassembly procedures on page 58), and then remove
the side access panel (
Removing the side access panel on page 64).
2. Attach a SAS-to-SATA cable adapter to the connector on the SAS hard drive.
Figure 4-49 Attaching the SAS-SATA adapter to the SAS hard drive
3. Install the four silver, ANSI 6–32 guide screws into the hard drive.
ENWW Removing and replacing components 97
