Designator Silkscreen Component
P23 FRNT AUDIO Front panel audio header
P24 FRNT USB Front panel USB header
P25 INT USB Internal USB header
U1037 U1037 Internal Type A USB
P29 P29 HDD LED connector
P5 CONTROL PANEL Main power/HDD LED/internal speaker
connector
P70 CPU FAN Primary processor fan header
P8 SYS FAN Chassis fan header
P9 PCI FAN PCI fan header
XBT1 BATTERY Battery retainer
XMM1 DIMM1 Memory slot
XMM2 DIMM3 Memory slot
XMM3 DIMM2 Memory slot
XMM4 DIMM4 Memory slot
U1 XU1 Primary processor socket
E15 E15 Crisis recovery header/jumper
164 Appendix B Appendix B—System board designators ENWW
