To recover the system after it enters Boot Block recovery mode:
1. If there is media in the diskette or optical drives, remove it.
2. Insert a BIOS image CD into the CD drive. USB media (such as an HP DriveKey) can also be used.
3. Power off, then power on the workstation.
If no BIOS image CD or USB is found, you are prompted to insert one and restart the workstation.
If a setup password has been established, the Caps Lock light illuminates and you are prompted
for the password.
4. Enter the setup password.
If the system successfully starts from the CD or USB and successfully reprograms the ROM, then
the three keyboard lights illuminate. A rising-tone series of beeps also signals successful recovery.
5. Remove the CD or USB media and power off the workstation.
6. Restart the workstation.
The following table lists the various keyboard light combinations used by the Boot Block ROM (when a
PS 2 keyboard is attached to the workstation) and explains the meaning and action associated with
each combination.
Table 3-2 Keyboard light combinations used by Boot Block ROM
FailSafe Boot
Block mode
Keyboard LED activity* State/Message
Num Lock On SoftPaq media is not present, is bad, or the drive not ready
Caps Lock On Enter password
Num, Caps,
Scroll Lock
Flash in sequence, one at
a time—N,C, SL
Keyboard locked in network mode
Num, Caps,
Scroll Lock
On Boot Block ROM Flash successful. Reboot the system
*Diagnostic lights do not flash on USB keyboards.
Asset tracking and security
Asset tracking features incorporated into your workstation provide asset tracking data that can be
managed using HP Systems Insight Manager (SIM), HP Client Manager Software, or other systems
management applications. Seamless, automatic integration between asset tracking features and these
products enables you to choose the management tool that is best suited to your environment and to
leverage investments in existing tools.
HP also offers several solutions for controlling access to valuable components and information. HP
ProtectTools Embedded Security, if installed, prevents unauthorized access to data, checks system
integrity, and authenticates third-party users attempting system access. Security features such as
ProtectTools and the Hood Sensor (Smart Cover Sensor) help prevent unauthorized access to your
data and to the internal components of the workstation. By disabling parallel, serial, or USB ports, or by
disabling removable-media boot capability, you can protect valuable data assets. Memory Change and
Hood Sensor (Smart Cover Sensor) alerts can be automatically forwarded to system management
applications to deliver proactive notification of tampering with a workstation’s internal components.
40 Chapter 3 System management ENWW

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
