If you enter the password incorrectly, a broken key icon appears. Try again. After three unsuccessful
tries, you must restart the workstation before you can continue.
Entering a Setup Password
If a setup password has been established on the workstation, you will be prompted to enter it each time
you run the Computer Setup (F10) Utility.
To enter a setup password:
1. Restart the workstation.
2. As soon as the workstation is powered on, press and hold the F10 key until you enter the Computer
Setup (F10) Utility. Press Enter to bypass the title screen, if necessary.
NOTE: If you do not press the F10 key at the appropriate time, you must restart the workstation
and press and hold the F10 key again to access the utility.
If you are using a PS 2 keyboard, you might see a keyboard error message—disregard it.
3. When the key icon appears on the monitor, enter the setup password, and press Enter.
NOTE: Type carefully. For security reasons, the characters you enter do not appear on the screen.
If you enter the password incorrectly, a broken key icon appears. Try again. After three unsuccessful
tries, you must restart the workstation before you can continue.
Changing a power-on or setup password
1. Restart the workstation.
2. To change the power-on password, go to step 4.
3. To change the setup password, as soon as the workstation is powered on, press and hold the
F10 key until you enter the Computer Setup (F10) Utility. Press Enter to bypass the title screen, if
necessary.
NOTE: If you do not press F10 at the appropriate time, you must restart the workstation, and then
press and hold the F10 key again to access the utility.
If you are using a PS 2 keyboard, you might see a keyboard error message—disregard it.
4. When the key icon appears, enter the current password, a slash (/) or alternative delimiter
character, your new password, another slash (/) or alternative delimiter character, and your new
password again as shown:
current password/new password/new password
See
National keyboard delimiter characters on page 44 for information about the alternative
delimiter characters.
NOTE: Type carefully. For security reasons, the characters you enter do not appear on the
screen.
5. Press Enter.
The new password takes effect the next time you power on the workstation.
ENWW Workstation management 43

Table of Contents

Other manuals for HP xw4600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP xw4600 and is the answer not in the manual?

HP xw4600 Specifications

General IconGeneral
Tcase72.4 °C
Bus typeFSB
SteppingE0
Processor cache6 MB
Processor cores2
Processor modelE8400
System bus rate- GT/s
Processor familyIntel® Core™2 Duo
Processor seriesIntel Core 2 Duo E8000 Series
Processor socketLGA 775 (Socket T)
Processor codenameWolfdale
Processing Die size107 mm²
Processor frequency3 GHz
Processor cache typeL2
Processor lithography45 nm
Processor manufacturerIntel
Processor front side bus1333 MHz
Processor operating modes64-bit
ECC supported by processorNo
Thermal Design Power (TDP)65 W
Number of processors installed1
CPU multiplier (bus/core ratio)9
Number of Processing Die Transistors410 M
Audio systemHigh Definition Audio
Product typeWorkstation
Motherboard chipsetIntel® X38 Express
ECCYes
Internal memory2 GB
Memory clock speed800 MHz
Internal memory typeDDR2-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)2 x 1 GB
HDD speed7200 RPM
HDD capacity250 GB
HDD interfaceSATA
Optical drive typeDVD-RW
Graphics card-
Networking featuresGigabit Ethernet (10/100/1000)
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply475 W
Chassis typeTower
Country of originChina
Processor codeSLB9J
Processor ARK ID33910
Processor package size37.5 x 37.5 mm
On-board graphics card modelNot available
Weight and Dimensions IconWeight and Dimensions
Depth456 mm
Width168 mm
Height450 mm
Weight19000 g
