Downloading the latest HP driver CD contents
To download the latest HP Driver CD:
1. Go to
http://www.hp.com and select Software and Drive Downloads.
2. Locate your workstation and operating system.
3. Select your driver CD and then follow the directions under the Release Notes.
Reinstalling the factory Linux image with the HP driver CD
1. Boot your workstation from the Red Hat box set, Binary CD 1.
2. When prompted, insert the Linux operating system restore media CDs.
3. Continue following the installation prompts until the operating system is successfully installed.
4. Configure the X server to start on reboot.
5. Reboot your workstation.
6. Follow the onscreen prompts to set up your system with the Red Hat First Boot utility.
7. When prompted by First Boot to add additional CDs, insert the HP Driver CD into the optical drive
of your workstation.
8. Select Install next to Additional CDs. The HP Driver CD window opens.
9. To begin the installation, select Press to continue.
When installation is complete, you are given two options— Reboot now... (on the left side), and
Press to continue, reboot later... (on the right side).
10. Select Reboot now...
Upgrading device drivers
To upgrade a Linux device driver, see http://www.hp.com/support/workstation_swdrivers.
Linux-enabled workstations
Linux-enabled workstations do not have Linux preinstalled, nor do they include installation media for a
Linux distribution. To install Linux, you must have the installation binary set for a Linux distribution (CD
or DVD media, or a version on your network), and the HP Installer Kit for Linux. The HP Installer kit
includes the HP CDs necessary to complete the installation of all versions of the distribution box set that
are supported by HP workstation hardware. See the Linux hardware support matrix at
http://www.hp.com/support/linux_hardware_matrix to determine which versions of are supported on
your workstation.
NOTE: If you want to use the drivers available in the HP Installer kit with Linux distributions other than
RHEL, you must manually extract the drivers from the HP Driver CD and install them. HP does not test
the installation of these drivers on other Linux distributions, nor does HP support this type of operation.
24 Chapter 2 Configuring and restoring the operating system ENWW

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
