HP xw4600 - Security Lock (Padlock Loop) (Optional); Removing the Security Lock; Cable Lock (Optional)

Hard drives (SAS hard drive
on page 96), SATA hard drive
on page 99)
Processor heatsink (Processor heatsink
on page 103)
Processor (System
processor on page 105)
System board (System board
on page 107)
Battery (Battery
on page 87)
Security lock (Padlock loop) (optional)
If a security padlock is installed on your workstation, remove it before servicing the workstation.
Removing the security lock
To remove the padlock, unlock it and slide it out of the padlock loop as shown in the following figure.
Figure 4-3 Removing the security lock
Cable lock (optional)
If a cable lock is installed on your workstation, remove it before servicing the workstation.
Table 4-5 Workstation component disassembly order (continued)
62 Chapter 4 Removal and replacement procedures ENWW
