HP xw4600 User Manual

Help tab
The Help tab provides three views:
●
HP Insight Diagnostics—Provides introductory and detailed information about Insight Field
Diagnostics.
●
Error Codes—Provides error code listings, including devices tested, messages, and
recommended repair information.
●
Test Components—Reloads and refreshes all components and displays component details after
the refresh.
POST error messages
Power On Self Test (POST) is a program run at startup that initializes and runs tests on installed
hardware. An audible and/or visual message appears if the POST encounters a problem. POST checks
the following items to ensure that the workstation system is functioning properly:
NOTE: If the power-on password is set, a key icon appears on the screen while POST is running. You
must enter the password before continuing.
Table 5-18 POST error messages
Screen message Probable cause Recommended action
101—Option ROM Error System ROM checksum Verify the correct ROM:
1. Flash the ROM, if needed.
2. If an expansion card was recently added, remove
it to find out if the problem remains.
3. Clear CMOS. If the message disappears, there
might be a problem with the expansion card
4. Replace the system board.
102—System Board Failure DMA, timers, and so on 1. Clear CMOS.
2. Remove expansion boards.
3. Replace the system board.
103—System Board Failure DMA, timers, and so on 1. Clear CMOS.
2. Remove expansion boards.
3. Replace the system board.
110—Out of Memory for
Option ROMs
Option ROM for a device was unable
to run due to memory constraints.
Run the Computer Setup (F10) Utility to enable the
ACPO/USB Buffers at Top of Memory under the
Advanced>Power-On option.
162—System Options Not Set Configuration incorrect. RTC battery
might need replacement.
1. Run Computer Setup (F10) Utility.
2. Set the date and time from the Control Panel or in
the setup utility (depending on the operating
system).
3. If the problem persists, replace the RTC battery.
ENWW POST error messages 135

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
