HP xw4600 - Power Supply Example Configuration 2

●
One 160-GB SATA hard drive
●
One optical drive
●
One diskette drive
●
One monitor, powered separately
Table 1-8 Power supply example configuration 1 energy consumption
115 VAC 230 VAC 100 VAC
LAN
Enabled
LAN
Disabled
LAN
Enabled
LAN
Disabled
LAN
Enabled
LAN
Disabled
Windows Idle (S0) 67.4W 66.4W 65.5W
Windows Busy Typ (S0) 89.7W 88.4W 88.2W
Windows Busy Max (S0) 114.1W 109.6W 110.0W
Sleep (S3)*
3.61W 2.82W 3.89W 3.12W 3.61W 2.82W
Power Off (S5) 1.51W 1.30W 1.81W 1.60W 1,50W 1.28W
* ENERGY STAR low energy mode.
Table 1-9 Power supply example configuration 1 heat dissipation**
115 VAC 230 VAC 100 VAC
LAN
Enabled
LAN
Disabled
LAN
Enabled
LAN
Disabled
LAN
Enabled
LAN
Disabled
Windows Idle (S0) 230.1 BTU/hr 226.6 BTU/hr 223.6 BTU/hr
Windows Busy Typ (S0) 306.3 BTU/hr 301.6 BTU/hr 300.9 BTU/hr
Windows Busy Max (S0) 389.4 BTU/hr 374.1 BTU/hr 375.4 BTU/hr
Sleep (S3)*
12.3 BTU/hr 9.62 BTU/hr 13.3 BTU/hr 10.6BTU/hr 12.3 BTU/hr 9.62 BTU/hr
Power Off (S5) 5.15 BTU/hr 4.44 BTU/hr 6.18 BTU/hr 5.46 BTU/hr 5.12 BTU/hr 4.37 BTU/hr
* ENERGY STAR low energy mode.
** Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.
NOTE: To reach zero power consumption, unplug the workstation from the power outlet or use a power
strip with a switch. For additional information on power-saving features, see your operating system
documentation.
Power supply example configuration 2
●
One 3.0 -GHz Intel® Core™ 2 Extreme QX6850 processor
●
Two 1-GB 800-MHz memory modules
●
Nvidia FX1700 graphics card
●
Two 73-GB SAS hard drives
ENWW Workstation specifications 9
