Subscriber’s Choice
Subscriber’s Choice is a client-based service from HP that supplies you with personalized product tips,
feature articles, and driver and support alerts and notifications based on your individual profile.
Subscriber’s Choice Driver and Support Alerts and Notifications delivers email notifying you that the
information you subscribed to in your profile is available for review and retrieval. To learn more about
Subscriber’s Choice and create a custom profile, see
http://www.hp.com/subscriberschoice.
ROM Flash
Your HP workstation comes with a programmable flash ROM. By establishing a setup password in the
Computer Setup (F10) Utility, you can protect the ROM from being inadvertently updated or overwritten.
This function is important to ensure the operating integrity of the workstation. To upgrade the ROM,
download the latest SoftPaq images from
http://www.hp.com//support/files.
NOTE: For maximum ROM protection, be sure to establish a setup password. The setup password
prevents unauthorized ROM upgrades. System Software Manager enables you to create the setup
password on one or more workstations simultaneously. For more information, see
http://www.hp.com/
go/ssm.
Remote ROM Flash
Remote ROM Flash allows system administrators to safely upgrade the ROM on remote HP
workstations directly from a centralized network management console, resulting in a consistent
deployment of, and greater control over, HP PC ROM images over the network.
To use Remote ROM Flash, the workstation must be powered on, or turned on using Remote Wakeup.
For more information about Remote ROM Flash, see the HP Client Manager Software or System
Software Manager sections at
http://www.hp.com/go/ssm.
HPQFlash
The HPQFlash utility is used to locally update or restore the system ROM on individual PCs through a
Windows operating system.
For more information about HPQFlash, visit
http://www.hp.com/go/ssm, and enter the name of your
workstation.
FailSafe Boot Block ROM
The FailSafe Boot Block ROM enables system recovery in the unlikely event of a ROM flash failure. For
example, if a power failure occurs during a ROM upgrade, the Boot Block uses a flash-protected section
of the ROM to check for a valid system ROM flash when power to the system is restored.
If the system ROM is valid, the system starts normally.
If the system ROM fails the validation check, the FailSafe Boot Block ROM provides enough support
to start the system from a BIOS image CD created from a SoftPaq. The BIOS image CD programs
the system ROM with a valid image.
When Boot Block detects an invalid system ROM, the workstation power LED blinks red eight times and
beeps eight times, then the workstation pauses for two seconds. Also, eight simultaneous beeps will be
heard. A Boot Block recovery mode message is displayed on the screen (some models).
In preparation for system recovery, use the BIOS CD media file in the SoftPaq to create a BIOS image
CD.
ENWW Workstation management 39

Table of Contents

Other manuals for HP xw4600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP xw4600 and is the answer not in the manual?

HP xw4600 Specifications

General IconGeneral
Tcase72.4 °C
Bus typeFSB
SteppingE0
Processor cache6 MB
Processor cores2
Processor modelE8400
System bus rate- GT/s
Processor familyIntel® Core™2 Duo
Processor seriesIntel Core 2 Duo E8000 Series
Processor socketLGA 775 (Socket T)
Processor codenameWolfdale
Processing Die size107 mm²
Processor frequency3 GHz
Processor cache typeL2
Processor lithography45 nm
Processor manufacturerIntel
Processor front side bus1333 MHz
Processor operating modes64-bit
ECC supported by processorNo
Thermal Design Power (TDP)65 W
Number of processors installed1
CPU multiplier (bus/core ratio)9
Number of Processing Die Transistors410 M
Audio systemHigh Definition Audio
Product typeWorkstation
Motherboard chipsetIntel® X38 Express
ECCYes
Internal memory2 GB
Memory clock speed800 MHz
Internal memory typeDDR2-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)2 x 1 GB
HDD speed7200 RPM
HDD capacity250 GB
HDD interfaceSATA
Optical drive typeDVD-RW
Graphics card-
Networking featuresGigabit Ethernet (10/100/1000)
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply475 W
Chassis typeTower
Country of originChina
Processor codeSLB9J
Processor ARK ID33910
Processor package size37.5 x 37.5 mm
On-board graphics card modelNot available
Weight and Dimensions IconWeight and Dimensions
Depth456 mm
Width168 mm
Height450 mm
Weight19000 g
