Using DriveLock
When one or more hard drives that support the ATA security command set are detected, the DriveLock
option appears under the Security menu in Computer Setup (F10). You are presented with options to
set the master password and to enable DriveLock. A user password must be provided to enable
DriveLock. Since the initial configuration of DriveLock is typically performed by a system administrator,
a master password should be set first. HP encourages system administrators to set a master password
whether they plan to enable DriveLock or not. This gives the administrator the ability to modify DriveLock
settings if the drive is locked in the future. Once the master password is set, the system administrator
might enable DriveLock or choose to leave it disabled.
If a locked hard drive is present, POST requires a password to unlock the device. If a power-on password
is set and it matches the device’s user password, POST does not prompt the user to re-enter the
password. Otherwise, the user is prompted to enter a DriveLock password. For a cold-boot, use the
master or user password. For a warm-boot, you must enter the same password used to unlock the drive
during the preceding cold-boot. Users are given two attempts to enter a correct password. During cold-
boot, if neither attempt succeeds, POST continues but the drive remains inaccessible. During a warm-
boot or restart from Windows, if neither attempt succeeds, POST halts and the user is instructed to cycle
power.
To enable and set the DriveLock user password:
1. Power on or restart the workstation.
2. As soon as the workstation is powered on, press and hold the F10 key until you enter the Computer
Setup (F10) Utility. Press Enter to bypass the title screen, if necessary.
NOTE: If you do not press the F10 key at the appropriate time, you must restart the workstation,
and then press and hold the F10 key again to access the utility.
If you are using a PS2 keyboard, you might see a keyboard error message—disregard it.
3. Select Security>DriveLock Security.
4. For each DriveLock-capable drive, select a drive by pressing the F10 key to accept.
5. Under Enable/Disable DriveLock options, select Enable, and then press the F10 key to enable
DriveLock for a particular drive.
CAUTION: Forgetting the DriveLock password renders the drive unusable.
6. Enter a new user password, and then press the F10 key to accept. This password may be 1 to 32
characters long.
7. Enter the password again in the Enter New Password Again field. If you forget this password, the
drive is rendered permanently disabled.
8. Select File>Save Changes and Exit, and then press the F10 key. After you press the F10 key,
the system performs a cold-boot before invoking the DriveLock function.
NOTE: This process can also be used to set the DriveLock master password by selecting Master in
Step 5.
When the workstation starts, you are prompted to enter the DriveLock password for each DriveLock-
capable drive for which you have previously set a password. You are given two attempts to enter the
password correctly. If the password is not entered correctly, the workstation attempts to boot anyway.
However, the boot process most likely fails because data from a locked drive cannot be accessed.
46 Chapter 3 System management ENWW

HP xw4600 Specifications

General

Tcase	72.4 °C
Bus type	FSB
Stepping	E0
Processor cache	6 MB
Processor cores	2
Processor model	E8400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo E8000 Series
Processor socket	LGA 775 (Socket T)
Processor codename	Wolfdale
Processing Die size	107 mm²
Processor frequency	3 GHz
Processor cache type	L2
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1333 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	65 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	9
Number of Processing Die Transistors	410 M
Audio system	High Definition Audio
Product type	Workstation
Motherboard chipset	Intel® X38 Express
ECC	Yes
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 1 GB
HDD speed	7200 RPM
HDD capacity	250 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	-
Networking features	Gigabit Ethernet (10/100/1000)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	475 W
Chassis type	Tower
Country of origin	China
Processor code	SLB9J
Processor ARK ID	33910
Processor package size	37.5 x 37.5 mm
On-board graphics card model	Not available

Weight and Dimensions

Depth	456 mm
Width	168 mm
Height	450 mm
Weight	19000 g
