PD Power Policy : Disabled
PD Disconnect Detection Mode : DC
Table 26 Command output
Field Description
PSE ID ID of the PSE.
Slot No. Slot number of the PSE.
SSlot No. Subslot number of the PSE.
Chassis In IRF mode, member ID of the device where the PSE resides.
PSE Status
PoE status of the PSE:
• Enabled.
• Disabled.
Preempted
Power preemption status for the PSE:
• No—The system has sufficient power for the PSE.
• Yes—The system has supplied power to other PSEs and does
not have sufficient power for this PSE.
Power Priority Power priority of the PSE.
Current Power Current power of the PSE.
Average Power Average power of the PSE.
Peak Power Peak power of the PSE.
Max Power Maximum power of the PSE.
Remaining Guaranteed Power
Remaining guaranteed power of the PSE = Maximum guaranteed
power of the PSE – Total maximum power of all critical PIs of the PSE.
PSE CPLD Version PSE CPLD version number.
PSE Software Version PSE software version number.
PSE Hardware Version PSE hardware version number.
Legacy PD Detection
Nonstandard PD detection status:
• Enabled.
• Disabled.
Power Utilization Threshold PSE power alarm threshold.
PSE Power Policy PSE power management policy mode.
PD Power Policy PD power management policy mode.
PD Disconnect Detection Mode PD disconnection detection mode.
display poe pse interface
Use display poe pse interface to display the PoE status of all PIs on a PSE.
Syntax
display poe pse pse-id interface
