405
Monitor port: GigabitEthernet1/0/2
GigabitEthernet1/0/3
GigabitEthernet1/0/4
Mirroring group 3:
Type: Local
Status: Active
Mirroring port:
GigabitEthernet1/0/5 Inbound
GigabitEthernet1/0/6 Both
Monitor port: GigabitEthernet1/0/7
Table 81 Command output
Field Description
Mirroring group Number of the mirroring group.
Type Type of the mirroring group: Local.
Status
Status of the mirroring group:
• Active—The mirroring group has taken effect.
• Incomplete—The mirroring group configuration is not complete and
does not take effect.
Mirroring port Source port.
Monitor port Destination port.
mirroring-group
Use mirroring-group to create a mirroring group.
Use undo mirroring-group to delete mirroring groups.
Syntax
mirroring-group group-id local
undo mirroring-group { group-id | all | local }
Default
No mirroring groups exist.
Views
System view
Predefined user roles
network-admin
Parameters
group-id: Specifies a mirroring group ID in the range of 1 to 6.
local: Specifies local mirroring groups.
all: Specifies all mirroring groups.
