(22) Suction temperature
sensor
(23) Low pressure sensor
● In Figure B-1, the pipelines in solid lines are installed by Huawei before delivery.
● In Figure B-1, the pipelines in dashed lines are to be routed onsite by technical
personnel.
● Huawei does not provide the oil trap and inverted trap. However, to ensure the normal
operating and easy maintenance of the cooling system, it is recommended that you use
these two components.
NetCol5000-A025 In-row Air Cooled Smart Cooling
Product
User Manual (300 mm Width) B Layout of the Cooling System
Issue 15 (2020-12-10) Copyright © Huawei Technologies Co., Ltd. 297
