Figure 3-29 Securing an indoor unit to a oor
----End
3.8.6 Installing Anchor Bae Plates
NO TICE
Install anchor bae plates only when you need to secure the indoor unit to a
base.
Secure each anchor bae plate to the cabinet using four M5x10 tapping screws,
as shown in Figure 3-30.
NO TICE
● The bent ange of the anchor bae plate faces the cabinet.
● Bae plates for the front and rear doors are installed in the same way.
