Parameter Description Conguration Principle
Return-air
temp set point,
Return-air
humid set
point
the return-air vent of the smart cooling
product to a temperature of 30°C and
humidity of 25% RH.
Cold-aisle
temp set point,
Cold-aisle
humid set
point
Hot-aisle temp
set point, Hot-
aisle humid set
point
Cold aisle
sensor 1, 2, 3
Sets the sensors in
cold aisles to
Enable.
Enable the corresponding humidity and
temperature sensor installed in the cold
aisle.
Hot aisle
sensor 1, 2, 3
Sets the sensors in
hot aisles to
Enable.
Enable the corresponding humidity and
temperature sensor installed in the hot
aisle.
----End
4.4.3.2 Setting Teamwork Control Parameters
Prerequisites
NO TICE
In the teamwork iCooling mode, each micro module supports only one teamwork
network, and all smart cooling products must be networked in the teamwork
mode. Smart cooling products managed by
dierent micro modules cannot be
networked in teamwork mode. Smart cooling products managed by each micro
module must be connected to the EMS separately.
Assign teamwork group number and teamwork unit address for the teamwork
controlled smart cooling products as follows:
● Teamwork group no.: Group the smart cooling products in adjacent areas as
one, that is, assign one teamwork control number for them. At most four
teamwork control groups can be assigned (1–4).
● Teamwork unit address: The address for the smart cooling product in the
same group cannot be the same (address range: 1–32). The smart cooling
product addressed 1 is the master one that collects, processes, and delivers
data. It is recommended that you set the unit address numbers from one to
