4.4.1 Powering On the Equipment
Context
Before starting the compressor, ensure that the electric heating belt of the
crankcase has been preheated for more than 12 hours. Otherwise, the compressor
will be damaged, and Huawei shall not be liable for any such consequences.
Procedure
Step 1 Switch on the smart cooling product switch in the upstream PDC.
Step 2 Verify that the QF3 switch that controls the outdoor unit and compressor, QF4
switch that controls the heater and
humidier, MD1, and MD2 are ON.
Step 3 When the device is powered on for the
rst time, log in as the Admin user. Then
set the following parameters on the displayed Quick Settings page:
● Select the language: Species the interface language.
● Select the date & time settings: date format, date, time, and time zone.
● Select the monitoring mode.
Step 4 Choose Settings > System Settings > T/H Sensor to enter the T/H Sensor screen.
You can
congure the T/H control types and set points.
----End
4.4.2 Home Screen
You can tap the menu items, buttons, or icons on the screen to enter related
screens or perform operations, such as Running, Alarms and Settings. The
controller main screen is shown in Figure 4-6.
User interfaces displayed in this document correspond to the ACC software version
V200R001C00SPC300 and are for reference only.
NetCol5000-A025 In-row Air Cooled Smart Cooling
Product
User Manual (300 mm Width) 4 Power-On Commissioning
Issue 15 (2020-12-10) Copyright © Huawei Technologies Co., Ltd. 108
