3.11.5.2 Teamwork Network
The smart cooling product supports two teamwork networking modes: CAN
teamwork networking (hand-in-hand) and FE teamwork networking. Select either
CAN teamwork networking or FE teamwork networking.
Smart cooling products in a teamwork group must be of the same model.
3.11.5.2.1 CAN teamwork networking
In CAN networking, a maximum of 32 smart cooling products can be teamworked.
Figure 3-53 Pin sequence of can teamwork networking cable
Step 1 Connect the CAN_OUT port of each smart cooling product to the CAN_IN port of
the following smart cooling product using a CAN network cable.
NetCol5000-A025 In-row Air Cooled Smart Cooling
Product
User Manual (300 mm Width) 3 Installation Guide
Issue 15 (2020-12-10) Copyright © Huawei Technologies Co., Ltd. 85
