Applicati
on
Scenario
Name Technical Specications Remarks
0-
A0265S1
1E0)
Power cable
(optional)
Electronic electric cable, 600 V,
ZA-RVV, 5 x 2.5 mm
2
, black (5
core wires: red, yellow, green,
blue, black), 27 A, outdoor
cable, CE
The length is
determined by site
survey.
M4/OT
terminal
Bare crimp terminal, OT, 2.5
mm
2
, M4, 27 A, tin plating,
16–14 AWG
Delivered with the
ttings
M6/OT
terminal
Bare crimp terminal, OT, 2.5
mm
2
, M6, 27 A, tin plating,
16–14 AWG
Delivered with the
ttings
Cord end
terminal
Bare crimp terminal, single
cord end terminal, 2.5 mm
2
,
12.5 A, tin plating, insertion
depth 8 mm, blue
Delivered with the
ttings
Outdoor
unit
(applicab
le to
NetCol50
0-
A026SC1
1E0)
Signal cable
(optional)
Balanced twisted pair, 100
ohm, SFTP CAT5E, 0.53 mm,
24 AWG, 4 pairs, black,
outdoor cable
Applicable to the
dry contact and
RS485 connection,
the length is
determined by site
survey.
1 PCS
Power cable
(optional)
Electronic electric cable, 300
V/500 V, 60227 IEC 10 (BVV), 3
x 2.5 mm
2
, black (3 core wires:
brown, blue, green-and-
yellow), 27 A, outdoor cable,
CCC, CE
The length is
determined by site
survey.
M4/OT
terminal
Bare crimp terminal, OT, 2.5
mm
2
, M4, 27 A, tin plating,
16–14 AWG
Delivered with the
ttings
Cord end
terminal
Bare crimp terminal, single
cord end terminal, 2.5 mm
2
,
12.5 A, tin plating, insertion
depth 8 mm, blue
Delivered with the
ttings
Teamwor
k control
networki
ng cable
and host
monitori
ng cable
Standard
network
cable
(optional)
Balanced twisted pair, 100
ohm, enhanced class-ve
cable, aluminum foil shield,
0.52 mm, 24 AWG, 8-core,
four pairs, PANTONE 430U,
equipped with plug 14080097
1 PCS (10 m)
