Context
● Route power cables from the top or bottom.
● For the switch and cable specications, see 3.1.2.7 Cable.
● The cables should be routed in from the cable clip.
CA UTION
Keep cables away from the compressor, fan, and copper pipe (if unavoidable, take
protective measures), and connect cables securely.
Procedure
Step 1 For single power supply, connect the external power cable to the L1, L2, L3, and N
ports of the AC1 terminal. For dual power supply, connect the external power
cable to the L1, L2, L3, and N ports of the AC1 and AC2 terminals. See Figure 3-45
and Figure 3-46.
Step 2 Connect the PE cable to the cabinet ground bar, as shown in Figure 3-45 and
Figure 3-46.
D ANGER
Ensure that there is no reverse or open phase for the input power cable of the
smart cooling product.
NO TICE
● When there is only one power supply, the power cable must connect to the
active power port (AC1).
● The ground cable must meet the local electrical
specications.
● In the bottom cabling scenario with dual power supplies, bind a cable 100 mm
above and below the sight glass respectively.
NetCol5000-A025 In-row Air Cooled Smart Cooling
Product
User Manual (300 mm Width) 3 Installation Guide
Issue 15 (2020-12-10) Copyright © Huawei Technologies Co., Ltd. 75
