IAI SEL User Manual

7. Simple Operation Procedure
100
90
Select the F4 (TAG) key and press the return key.
Enter a numerical value of 1 for operation 1 and
press the return key.
Press the WRT key to transfer the program data to
the controller.
* When the screen is changed with the PAGE UP
and PAGE DOWN keys or ESC key before data
transfer, the input data becomes invalid.
Press the ESC key twice to display the screen for
step No. 6.
Then, delete “MOVP 1” from pre-modification step
No. 9. Enter 10 for the step No. directly with the 10
key while keeping the cursor position, or press the
PAGE UP key 4 times to display “MOVP 1.”
(Cursor located at step No. 10)

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
