IAI SEL User Manual

10. Position Edit
135
122
④
Jog movement on each axis system (jog movement on each arm)
Each arm, jog keys and movement directions are as shown below.
In the case of each axis
system, the position display on
the teaching screen cannot be
incorporated.
Jog movement on each
axis system
To change the coordinate system for
jog operation, press the F4 (JCrd) key.
To switch between the input data
screen and the current position
display, press the F1 (Disp) key.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
