16. Controller

244

224

Absolute reset jig (Plate)

Absolute reset jig (Pin)

Turn and press the

rotation axis so that no

clearance will be made.

Set the plate so that a hole of φ

3 will be placed on the opposite

side of the D-cut surface.

(Bottom view)

Arm Length 120 Reference Position
