277

17. Gateway Function Associated

277

(5) Data Transfer to the Controller

The captured data is transferred to the controller.

Press the key and write the input position data

in the controller.

CAUTION :

Unless the key is pressed, the input data

writing in the controller is not performed.

When the writing is completed, the screen is

switched to the display for the next Position No.
