7. Simple Operation Procedure

The cursor moves to the second axis position data.

Input 100 and press return key.

Transmit the data with the WRT key and move to

position No. 3.

③

Data input for the third point

Input 100 for the first axis position data and press

the return key.

Input 50 for the second axis position data and press

return key.

Transmit the data with the WRT key and move to

position No. 4.
