IAI SEL User Manual

7. Simple Operation Procedure
72
62
Input 1 on position No. and press the return key.
Transmit the data to the controller by pressing the
WRT key.
The cursor moves to step No.4.
* If you change the screen with the PAGE UP ·
PAGE DOWN or ESC keys before transmitting
the data, the input data will be invalid.
Input MOVL 2 ~ MOVL 6 program data into steps
No. 4 ~ 8 by the same procedure and transmit the
data to the controller.
Display EXIT in the function key area by using the
, SF and keys.
Select the F4 key (EXIT) and press the return key.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
