IAI SEL User Manual

7. Simple Operation Procedure
73
63
Transmit the data to the controller by pressing the
WRT key.
* If you change the screen with the PAGE UP ·
PAGE DOWN or ESC keys before transmitting
the data, the input data will be invalid.
Finish editing the program and write the data to
Flash ROM.
Press the ESC key.
(The cursor moves to the step No.)
Press the ESC key.
(The cursor moves to the program No.)
Press the ESC key.
Return to the program edit screen.
Press the ESC key.
Return to the edit mode screen.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
