5. Attach the power cords and other cables to the rear of the enclosure 1. Route
the cables and power cord on the cable-management arm and secure them with
cable ties or hook-and-loop fasteners 2.
Note: Allow slack in all cables to avoid tension in the cables as the
cable-management arm moves.
6. Power on the 7226 Storage Enclosure.
7. Refer to your system manuals to verify installation.
Servicing the 7226 Storage Enclosure is now complete.
ROLSOS811-0
1
2
Figure 112. Cable Routing
Chapter 11. Installation and Removal Procedures 179
