7. Ensure that the system and the 7226 Storage Enclosure are powered off.
8. Attach the power cords and other cables to the rear of the 7226 Storage
Enclosure 1. Route the cables and power cords on the cable-management arm
and secure them with cable ties or hook-and-loop fasteners 2.
Note: Allow slack in all cables to avoid tension in the cables as the
cable-management arm moves.
9. Slide the 7226 Storage Enclosure into the rack until it snaps into place.
ROLSOS811-0
1
2
Figure 15. Power cord attachment and routing
Chapter 2. Installing the 7226 Storage Enclosure into a Rack 21
