IMBA-8650 Motherboard
Page 91
The following external peripheral devices (if applicable) are properly
connected to the chassis:
o VGA screen
o Keyboard
o Mouse
o USB devices
o LAN
o Audio jacks
5.3 CPU, CPU Cooling Kit and DIMM Installation
WARNING!
A CPU should never be turned on without the specified cooling kit
being installed. If the cooling kit (heat sink and fan) is not properly
installed and the system turned on, permanent damage to the CPU and
other electronic components attached to the system may be incurred.
Running a CPU without a cooling kit may also result in injury to the
user.
The CPU, CPU cooling kit and DIMM are the most critical components of the IMBA-8650.
If any of these components is not installed, the IMBA-8650 cannot operate.
5.3.1 Socket 478 CPU Installation
WARNING:
CPUs are expensive and sensitive components. When installing the
CPU please be careful not to damage it in anyway. Make sure the CPU
is installed properly and ensure the correct cooling kit is properly
installed.
