IMBA-8650 Motherboard
Page 50
Connector Type Label
Serial port connector (RS-232/422/485) 10-pin box header COM3
Serial port connector (RS-422/485) 4-pin header CN12
SPDIF connector 5-pin header CN8
USB connector 8-pin header USB2
USB connector 8-pin header USB3
Table 4-1: Peripheral Interface Connectors
4.1.3 External Peripheral Interface Panel Connectors
Table 4-2 lists the external peripheral interface panel connectors on the IMBA-8650.
Detailed descriptions of these connectors can be found in.
Connector Type Label
Keyboard/Mouse PS/2 KB/MS1
Parallel port connector DB-25 (female) PRN1
VGA connector DB-15 (female) VGA1
Serial connector DB-9 (male) COM1
USB connector Dual USB port connector USB1
Ethernet/USB connector RJ-45/USB port combo connector LAN/USB1
Audio connector 3 x Audio jacks CN1
Table 4-2: External Peripheral Interface Panel Connectors
4.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the IMBA-8650.
