IMBA-8650 Motherboard
Page 98
The CF Master/Slave Selection jumper sets the CF Type I card or CF Type II cards as
either the slave device or the master device. CF Master/Slave Selection jumper settings
are shown in
Table 5-2.
Pins Description
Open Slave
Short Master Default
Table 5-2: CF Master/Slave Selection Settings
5.4.2 Clear CMOS Jumper
Jumper Label:
JP1
Jumper Type:
3-pin header
Jumper Settings:
See
Table 5-3
Jumper Location:
See
Figure 5-6
If the IMBA-8650 fails to boot due to improper BIOS settings, the clear CMOS jumper
clears the CMOS data and resets the system BIOS information. To do this, use the jumper
cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1
and 2.
If the “CMOS Settings Wrong” message is displayed during the boot up process, the fault
may be corrected by pressing the F1 to enter the CMOS Setup menu. Do one of the
following:
Enter the correct CMOS setting
Load Optimal Defaults
Load Failsafe Defaults.
After having done one of the above, save the changes and exit the CMOS Setup menu.
The clear CMOS jumper settings are shown in
Table 5-3.
Pins Description
