Figure 2-11: LPC Interface
The LPC bus from the ICH5 is connected to the following components:
 BIOS chipset
 Super I/O chipset
 Fintek serial port chipset
2.6.5 Intel
®
ICH5 PCI Interface
The PCI interface on the ICH5 is compliant with the PCI Revision 2.3 implementation.
Figure 2-12: PCI Interface
