IMBA-8650 Motherboard
Page 7
Specification IMBA-8650
One on-board RS-232/422/485 serial port (by jumper setting)
USB 2.0
Eight USB 2.0 devices supported
IDE
Two 40-pin IDE connects up to four Ultra ATA33/66/100 devices
Floppy Disk
One FDD connector supports one floppy disk drive
SATA
Two SATA 1.5Gb/s drives supported
Keyboard/mouse
One PS/2 connector supports mouse and keyboard connectivity
Watchdog Timer
Software programmable 1-255 sec. by super I/O
Power Supply
12V@7.3A, 5V@4.9A, 3.3V@0.7A, -12V@0.2A, 5VSB@0.7A
(Pentium® 4 3.0GHz CPU with 1GB DDR 400MHz)
Temperature
0ºC ~ 60ºC (32ºF ~140ºF)
Humidity (operating)
5%~95% non-condensing
Dimensions
305mm x 244mm
Weight (GW/NW)
1.2kg/0.6kg
Table 1-1: Technical Specifications
