PIN DESCRIPTION PIN DESCRIPTION
6 VCC 16 GND
7 GND 17 GND
8 RAWS- 18 -5V
9 5VSB 19 VCC
10 +12V 20 VCC
Table 4-5: ATX Power Connector Pinouts
4.2.4 Audio Connector (7-pin)
CN Label: CN6
CN Type:
7-pin header (2x4)
CN Location:
See
Figure 4-5
CN Pinouts:
See
Table 4-6
The 8-pin audio connector is connected to external audio devices including speakers and
microphones for the input and output of audio signals to and from the system.
Figure 4-5: Audio Connector Location (7-pin)
