IEI Technology IMBA-8650 User Manual

IMBA-8650 Motherboard
Page 73
PIN DESCRIPTION PIN DESCRIPTION
A33 +3.3V B33 C/BE2
A34 FRAME- B34 GND
A35 GND B35 IRDY
A36 TRDY- B36 +3.3V
A37 GND B37 DEVSEL
A38 STOP- B38 GND
A39 +3.3V B39 LOCK
A40 SDONE B40 PERR
A41 SBO- B41 +3.3V
A42 GND B42 SERR
A43 PAR B43 +3.3V
A44 AD15 B44 C/BE1
A45 +3.3V B45 AD14
A46 AD13 B46 GND
A47 AD11 B47 AD12
A48 GND B48 AD10
A49 AD9 B49 GND
A50 KEY B50 KEY
A51 KEY B51 KEY
A52 C/BE0 B52 AD8
A53 +3.3V B53 AD7
A54 AD6 B54 +3.3V
A55 AD4 B55 AD5
A56 GND B56 AD3
A57 AD2 B57 GND
A68 AD0 B68 AD1
A59 +5V B59 +5V
A60 REQ64 B60 ACK64
A61 +5V B61 +5V
A62 +5V B62 +5V
Table 4-16: PCI Slot
