Figure 4-8: CF Card Socket Location
PIN DESCRIPTION PIN DESCRIPTION
1 GND 26 CFD1
2 DATA 3 27 DATA 11
3 DATA 4 28 DATA 12
4 DATA 5 29 DATA 13
5 DATA 6 30 DATA 14
6 DATA 7 31 DATA 15
7 HDC_CS0# 32 SDCS3-
8 N/C 33 N/C
9 GND 34 SIOR-
10 N/C 35 SIOW-
11 N/C 36 VCC
12 N/C 37 IRQ15
