IEI Technology IMBA-8650 User Manual

IMBA-8650 Motherboard
Page 69
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
2 LA23 20 IOCS16#
3 LA22 21 IRQ10
4 LA21 22 IRQ11
5 LA20 23 IRQ12
6 SA19 24 IIRQ15
7 SA18 25 IIRQ14
8 SA17 26 DACK#0
9 MEMR# 27 DRQ0
10 MEMW# 28 DACK#5
11 SD8 29 DRQ5
12 SD9 30 DACK#6
13 SD10 31 DRQ6
14 SD11 32 DACK#7
15 SD12 33 DRQ7
16 SD13 34 VCC
17 SD14 35 MASTER#
18 SD15 36 GND
Table 4-14: PCI Slot
4.2.13 Infrared Interface Connector (5-pin)
CN Label:
IR1
CN Type:
5-pin header (1x5)
CN Location:
See
Figure 4-14
CN Pinouts:
See
Table 4-15
The infrared interface connector supports both Serial Infrared (SIR) and Amplitude Shift
Key Infrared (ASKIR) interfaces.
