IEI Technology IMBA-8650 User Manual

IMBA-8650 Motherboard
Page 68
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
2 SD7 33 RSTDRV
3 SD6 34 VCC
4 SD5 35 IRQ9
5 SD4 36 -5V
6 SD3 37 DRQ2
7 SD2 38 -12V
8 SD1 39 NOWS#
9 SD0 40 +12V
10 IOCHRDY 41 GND
11 AEN 42 SMEMW#
12 SA19 43 SMEMR#
13 SA18 44 IOW#
14 SA17 45 IOR#
15 SA16 46 DACK#3
16 SA15 47 DRQ3
17 SA14 48 DACK#1
18 SA13 49 DRQ1
19 SA12 50 REFRESH#
20 SA11 51 CLK2
21 SA10 52 IRQ7
22 SA9 53 IRQ6
23 SA8 54 IRQ5
24 SA7 55 IRQ4
25 SA6 56 IRQ3
26 SA5 57 CACK#2
27 SA4 58 TC
28 SA3 59 BALE
29 SA2 60 VCC
30 SA1 61 OSC2
31 SA0 62 GND
1 SBHE# 19 MEMCS16#
