IMBA-8650 Motherboard
Page 112
Step 2: Insert a USB Series "A" plug. Insert the USB Series "A" plug of a device into the
USB Series "A" receptacle on the external peripheral interface. See
Figure 5-17.
Step 0:
Figure 5-17: USB Connector
5.7.5 Audio Connection
Audio signals are interfaced through three phone jack connections. The red phone jack is
for Mic In, blue is for Line In and green is for Speaker Out. Follow the steps below to
connect audio devices to the IMBA-8650.
Step 1: Locate the audio phone jacks. The location of the audio phone jacks are shown
in Chapter 3.
Step 2: Insert audio phone jack plugs. Insert audio phone jack plugs into the audio
phone jacks on the external peripheral interface. See
Figure 5-18. Step 0:
