IMBA-8650 Motherboard
Page 49
Connector Type Label
+12V ATX power connector 4-pin header CN5
AGP slot 66-pin AGP 8X slot AGP1
ATX power connector 24-pin header ATX1
Audio connector 7-pin header CN6
Auxiliary audio connector 4-pin header CN3
CD-in connector 4-pin header CN4
CompactFlash connector 50-pin CF slot CF1
Fan connector 3-pin wafer FAN1
Fan connector 3-pin wafer FAN2
Floppy disk drive connector 34-pin box header FDD1
Front panel connector 12-pin header CN11
IDE Interface connector 40-pin box header IDE1
IDE Interface connector 40-pin box header IDE2
ISA slot 98-pin ISA slot ISA1
ISA slot 98-pin ISA slot ISA2
Infrared connector 5-pin header IR1
PCI slot 124-pin PCI slot PCI1
PCI slot 124-pin PCI slot PCI2
PCI slot 124-pin PCI slot PCI3
PCI slot 124-pin PCI slot PCI4
PCI slot 124-pin PCI slot PCI5
SATA drive connector 7-pin SATA SATA1
SATA drive connector 7-pin SATA SATA2
Serial port connector (RS-232) 10-pin box header COM2
Serial port connector (RS-232) 10-pin box header COM4
Serial port connector (RS-232) 10-pin box header COM5
Serial port connector (RS-232) 10-pin box header COM6
