IMBA-8650 Motherboard
Page 52
CN Type:
66-pin AGP slot
CN Location:
See
Figure 4-3
CN Pinouts:
See
Table 4-4
Use the 66-pin AGP slot to connect an AGP 3.0 compliant graphics card.
