IMBA-8650 Motherboard
Page 54
PIN
B A
PIN
B A
1 OVRCNT# 12V 34 VDDQ3.3 VDDQ3.3
2 5.0V TYPEDET# 35 AD21 AD22
3 5.0V RESERVED
36 AD19 AD20
4 USB+ USB- 37 GND GND
5 GND GND 38 AD17 AD18
6 INTB# INTA# 39 C/BE2# AD16
7 CLK RST# 40 VDDQ3.3 VDDQ3.3
8 REQ# GNT# 41 IRDY# FRAME#
9 VCC3.3 VCC3.3 42 KEY KEY
10 ST0 ST1 43 KEY KEY
11 ST2 RESERVED
44 KEY KEY
12 RBF# PIPE# 45 KEY KEY
13 GND GND 46 DEVSEL# TRDY#
14 SPARE WBF# 47 VDDQ3.3 STOP#
15 SBA0 SBA1 48 PERR# PME#
16 VCC3.3 VCC3.3 49 GND GND
17 SBA2 SBA3 50 SERR# PAR
18 SB_STB SBSTB# 51 C/BE1# AD15
19 GND GND 52 VDDQ3.3 VDDQ3.3
20 SBA4 SBA5 53 AD14 AD13
21 SBA6 SBA7 54 AD12 AD11
22 RESERVED RESERVED
55 GND GND
23 GND GND 56 AD10 AD9
24 3.3V AUX RESERVED
57 AD8 C/BE0#
25 VCC3.3 VCC3.3 58 VDDQ3.3 VDDQ3.3
26 AD31 AD30 59 AD_STB0 AD_STB0#
27 AD29 AD28 60 AD7 AD6
28 VCC3.3 VCC3.3 61 GND GND
29 AD27 AD26 62 AD5 AD4
30 AD25 AD24 63 AD3 AD2
31 GND GND 64 VDDQ3.3 VDDQ3.3
To Next Page
