Intel740™ Graphics Accelerator Design Guide
Table 2-1 lists the various functions capable of being supported by the reference card design. This
table describes which component is necessary for a specific feature. For hookup information, the
corresponding schematic page should be referenced.
Intel740™ Graphics Acc elerator
2.1.1 Design Features
2.1.1.1 Intel740™ Graphics Accelerator
The Intel740™ graphics accelerator is the main component of the graphics reference design. This
component delivers high performance 3D/2D graphics and video capabilities. Each of the
interfaces are described below.
•
Accelerated Graphics Port (AGP) Interface. The AGP interface is a new interface designed
for 3D graphics. This interface provides increased bandwidth over PCI, side band addressing,
and AGP memory 3D texture storage. For a more complete description of the AGP interface
refer to the Intel740™ Graphics Accelerator Datasheet and AGP Specification.
•
Local Memory Interface. The memory interface on the Intel740™ graphics accelerator can
operate at speeds up to 100 MHz. An SDRAM interface supports SGRAM and SDRAM to be
used for different memory densities.
•
VMI Interface. A bi-directional VMI like port is incorporated into the Intel740™ graphics
accelerator providing a mechanism for affordable DVD. Video capture is also supported using
the video port pins.
•
TV Out Interface. Intel has worked with Rockwell* (Brooktree*) to design an interface
capable of supporting a high quality TV out chip. This interface allows the Intel740™ graphics
accelerator to output on a monitor, TV, or both.
•
BIOS Interface. The Intel740™ graphics accelerator supports a FLASH or ROM BIOS. Up
to 256Kx8 can be supported.
•
GPIO Interface. Nine GPIO signals exist on the Intel740™ graphics accelerator. GPIO[8:0]
allow for power management, DDC, I
2
C, thermal fault sensing, and other general features.
•
DAC Interface. An integrated DAC provides display resolutions up to 1600x1200.
Table 2-1. Mix and Match Options For Intel740™ Graphics Accelerator Card
Component/
Functionality
Intel740™
Graphics
Accelerator
Page 3
BT829
Page 5
BT869
Page 6
DVD Chip/
Daughter
Card
Page 7
SO-DIMM
Module
Page 11
Memory
Components
Page 12
2D/3D X
Video Capture X X
TV Out X X
DVD (HW) X X
2 MB X (1) 256K x 64 (2) 256K x 32
4 MB X
(1) 512K x 64
or
(2) 256K x 64
(2) 512K x 64
or
(4) 256K x 32
8 MB X (1) 1M x 64 (4) 1M x 16
