Intel 740 - 10 Ns Timing

Revision 0.91
13
SO-DIMM Module — Unbuffered SDRAM/SGRAM Graphics
7.3 10 nS Timing
7.4 8 nS Timing
Parameter Symbol Min. Max. Unit
Clock Cycle Time Tcyc 10.0 nS
Early/Late Clock Tcsk 1.3 1.8 nS
Output Valid from Clock Tac 7.0 nS
Output Hold from Clock Toh 2.5 nS
Input Setup Time Tsi 2.5 nS
Input Hold Time Thi 1.0 nS
Motherboard Clock Flight Time Tcfm 0.2 0.3 nS
Motherboard Addr/Data/Cntrl Flight Time Txfm 0 0.3 nS
Module Clock Flight Time Tcfs 0.175 0.325 nS
Module Flight Addr/Data/Cntrl Flight Time Txfs 0 0.375 nS
Parameter Symbol Min. Max. Unit
Clock Cycle Time Tcyc 8.0 nS
Early/Late Clock Tcsk 1.3 1.8 nS
Output Valid from Clock Tac 6.0 nS
Output Hold from Clock Toh 2.5 nS
Input Setup Time Tsi 2.0 nS
Input Hold Time Thi 1.0 nS
Motherboard Clock Flight Time Tcfm 0.2 0.3 nS
Motherboard Addr/Data/Cntrl Flight Time Txfm 0 0.3 nS
Module Clock Flight Time Tcfs 0.175 0.325 nS
Module Flight Addr/Data/Cntrl Flight Time Txfs 0 0.375 nS
