3.3 Color Register
Data is loaded into the Color Register through the Special Mode Register Write command. During
the execution of the Special Mode Register Command, bit A[6] is used to determine if a new value
is to be loaded into the Mask registers. If A[6] =1 during the special mode register command, then
the value on DQ[31:0] is loaded into the Color Register. The color register supplies data for the
block write command.
Table 4. Color Register
Bit Default Attribute Description
31:0 00000000h WO
Color Register Data: Data from these bits is used for Block
Write Command.
