Hardware Installations and Upgrades
Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide (Preliminary) 157
To access this screen from the Main screen or other top-level “Tab” screen, press the right or left arrow
keys to traverse the tabs at the top of the Setup screen until the Boot Manager screen is selected.
Figure 144. Boot Manager Screen
Main Advanced Security Server Management Boot Options Boot Manager
<Internal EFI Shell>
<Boot device #1>
<Boot Option #2>
<Boot Option #n>
Screen Field Descriptions
:
Error Manager Screen (Tab)
The Error Manager screen displays any POST Error Codes encountered during BIOS POST, along with
an explanation of the meaning of the Error Code in the form of a Help Text. This is an Information Only
screen.
To access this screen from the Main screen or other top-level “Tab” screen, press the right or left arrow
keys to traverse the tabs at the top of the Setup screen until the Error Manager screen is selected.
Figure 145. Error Manager Screen
Error Manager Exit
ERROR CODE SEVERITY INSTANCE
<Post Code> <Major/Minor> <Instance #>> <Description>
5224 Major N/A This is an example.
Screen Field Descriptions
:
Exit Screen (Tab)
The Exit screen allows the user to choose whether to save or discard the configuration changes made on
other Setup screens. It also allows the user to restore the BIOS settings to the factory defaults or to save or
restore them to a set of user-defined default values. If Load Default Values is selected, the factory default
settings (noted in bold in the Setup screen images) are applied. If Load User Default Values is selected,
the system is restored to previously saved user-defined default values.
