Intel S2600CP User Manual

Hardware Installations and Upgrades
Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide (Preliminary) 123
Figure 130. System Acoustic and Performance Configuration
Advanced
System Acoustic and Performance Configuration
Set Throttling Mode Auto/DCLTT/SCLTT/SOLTT
Altitude 300m or less/301m-900m/901m – 1500m/Higher than 1500m
Set Fan Profile Performance/Acoustic
Fan PWM Offset [0 – 100, 0 is default]
Screen Field Descriptions:
1. Set Throttling Mode
Option Values: Auto
DCLTT
SCLTT
SOLTT
Help Text:
Sets Thermal Throttling mode for memory, to control fans and DRAM power as needed to
control DIMM temperatures.
[Auto] – BIOS selects mode.
[DCLTT] – Dynamic Closed Loop Thermal Throttling.
[SCLTT] – Static Closed Loop Thermal Throttling.
[SOLTT] – Static Open Loop Thermal Throttling.
Comments: The Thermal Throttling Mode chosen reflects whether the DIMMs have
Temperature Sensors (TSOD), and whether the chassis is an Intel chassis for which thermal data
are available. Note that this is for thermal throtting only, independent of any controls imposed for
the purpose of power limiting.
 DCLTT
is the expected mode for a board in an Intel chassis with inlet and outlet air
temperature sensors and TSOD. The firmware can update the offset registers for
closed loop during runtime, as BIOS sends the dynamic CLTT offset temperature
data.
 SCLTT
would be used with an OEM chassis and DIMMs with TSOD. The firmware
does not change the offset registers for closed loop during runtime, although the
Management Engine can do so.
 SOLTT
is intended for a system with UDIMMs which do not have TSOD. The
thermal control registers are configured during POST, and the firmware does not
change them.
Back to [System Acoustic and Performance Configuration]
