Hardware Installations and Upgrades
Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide (Preliminary) 131
2. Reset on ERR2
Option Values: Enabled
Disabled
Help Text:
When enabled system gets reset upon encountering ERR2 (Fatal error); when disabled
system does not get reset on ERR2
Comments: This option controls whether the system will be reset if the BMC’s ERR2
Monitor times out, that is, the ERR2 signal has been continuously asserted long enough to
indicate that the SMI Handler is not able to service the condition
Back to [Server Management Screen]
3. Resume on AC Power Loss
Option Values: Stay Off
Last State
Power On
Help Text:
System action to take on AC power loss recovery.
[Stay Off] - System stays off.
[Last State] - System returns to the same state before the AC power loss.
[Power On] - System powers on.
Comments: This option controls the policy that the BMC will follow when AC power
is restored after an unexpected power outage. The BMC will either hold DC power off or turn it
on to boot the system, depending on this setting – and in the case of “Last State”, whether the
power was on and the system was running before the AC power went off.
Back to [Server Management Screen]
Console Redirection
The Console Redirection screen allows the user to enable or disable Console Redirection for Remote
System Management, and to configure the connection options for this feature.
When Console Redirection is active, all POST and Setup displays are in Text Mode. The Quiet Boot
setting is disregarded, and the Text Mode POST Diagnostic Screen will be displayed regardless of the
Quiet Boot setting. This is due to the limitations of Console Redirection, which is using data transfer
based on serial data terminal emulation.
To access this screen from the Main screen, select Server Management > Console Redirection. To move
to another screen, press the <Esc> key to return to the Server Management screen, then select the desired
screen.
