Hardware Installations and Upgrades
132 Intel
®
Server Board S2600CP Intel
®
Server System P4000CP Family Service Guide
Figure 133. Console Redirection Screen
Server Management
Console Redirection
Console Redirection Disabled / Serial Port A / Serial Port B
Screen Field Descriptions
:
1. Console Redirection
Option Values: Disabled
Serial Port A
Serial Port B
Help Text:
Console redirection allows a serial port to be used for server management tasks.
[Disabled] - No console redirection.
[Serial Port A] - Configure serial port A for console redirection.
Enabling this option will disable display of the Quiet Boot logo screen during POST.
Comments: Serial Console Redirection can use either Serial Port A or Serial Port B.
If SOL is also going to be configured, note that SOL is only supported through Serial Port A.
When Console Redirection is set to Disabled
, all other options on this screen will be grayed out
and unavailable.
Only Serial Ports which are Enabled
should be available to choose for Console Redirection. If
neother Serial A nor Serial B is set to Enabled
, then Console Redirection will be forced to
Disabled
, and grayed out as inactive. In that case, all other options on this screen will also be
grayed
Back to [Console Redirection]
System Information
The System Information screen allows the user to view part numbers, serial numbers, and firmware
revisions. This is an Information Only
screen
To access this screen from the Main screen, select Server Management > System Information. To move
to another screen, press the <Esc> key to return to the Server Management screen, then select the desired
screen.
